Part name

Specification

Material& brand

QTY

Note

Screen

60-120

SUS316

One for each layer

Screen Overbraid

0.8

SUS316

1 set

Vibrating motor

0.55KW

Siemens

1 set

body

2.0mm

SUS316

1 set

seat

3.0mm

SUS304

1 set

START/STOP Button

1 set

No.

Name

parameter

1

Production capacity

50-500kg/h

2

Vibration Motor power

0.55kw

380V 50Hz

3

Effective screen diameter

Ф1000mm

4

Vibrating Freq(t/min)

1440 time/min

5

amplitude (of vibration)

1～5mm

6

Screen layer

Two layers with three discharge ports

7

Screen mesh

3-200 mesh

（mesh can be customized）

8

Material

SUS316

9

Dimension（L×W×H）

1500×1150×1278 mm

10

Weight

300kg
